Takeoff Weight(Without Accessories)

905 g

Dimensions(L×W×H)

Folded： 214×91×84 mm
Unfolded: 322×242×84 mm
Unfolded+Spotlight：322×242×114 mm
Unfolded+Beacon：322×242×101 mm
Unfolded+Speaker：322×242×140 mm

Diagonal Length

354 mm

Max Ascent Speed

5 m/s (S-mode[1])
4 m/s (P-mode)
4 m/s (S-mode with accessories[1])
4 m/s (P-mode with accessories)

Max Descent Speed

3 m/s (S-mode[1])
3 m/s (P-mode)

Max Speed (near sea level, no wind)

72 kph (S-mode，without wind)
50 kph (P-mode，without wind)

Max Service Ceiling Above Sea Level

6000 m

Max Flight Time (no wind)

31 min (at a consistent speed of 25 kph)

Max Hovering Time (no wind)

29 min
27 min (with beacon turned on)
28 min (with beacon turned off)
22 min (with spotlight turned on)
26 min (with spotlight turned off)
25 min (with speaker turned on)
26 min (with speaker turned off)

Max Wind Speed Resistance

29–38 kph

Max Tilt Angle

35° (S-mode, with remote controller)
25° (P-mode)

Max Angular Velocity

200°/s（S-Mode）
100°/s（P-Mode）200°/s（S-Mode）
100°/s（P-Mode）

Operating Temperature Range

-10°C to 40°C

GNSS

GPS+GLONASS

Operating Temperature Range

Vertical:
±0.1 m (with Vision Positioning)
±0.5 m (with GPS Positioning)
Horizontal: ±0.3m (with Vision Positioning)
±1.5 m (with GPS Positioning)

Operating Frequency

2.400 - 2.4835 GHz
5.725 - 5.850 GHz

Transmission Power (EIRP)

2.400 - 2.4835 GHz
FCC：≤26 dBm
CE：≤20 dBm
SRRC：≤20 dBm
MIC：≤20 dBm5.725-5.850 GHz
FCC：≤26 dBm
CE：≤14 dBm
SRRC：≤26 dBm

Internal Storage

24 GB

Sensing System

Omnidirectional Obstacle Sensing [2]

Forward

Precision Measurement Range:0.5 - 20 m
Detectable Range: 20 - 40 m
Effective Sensing Speed: ≤ 14m/s
FOV: Horizontal: 40°, Vertical: 70°

Backward

Precision Measurement Range: 0.5 - 16 m
Detectable Range: 16 - 32 m
Effective Sensing Speed: ≤ 12m/s
FOV: Horizontal: 60°, Vertical: 77°

Upward

Precision Measurement Range: 0.1 - 8 m

Downward

Precision Measurement Range: 0.5 - 11 m
Detectable Range: 11 - 22 m

Sides

Precision Measurement Range:0.5 - 10 m
Effective Sensing Speed: ≤ 8m/s
FOV: Horizontal: 80°, Vertical: 65°

Operating Environment

Forward, Backward and Sides:
Surface with clear pattern and adequate lighting (lux > 15)
Upward:
Detects diffuse reflective surfaces (>20%)
(walls, trees, people, etc.)
Downward:
Surface with clear pattern and adequate lighting (lux > 15)
Detects diffuse reflective surfaces (>20%)
(walls, trees, people, etc.)

Operating Frequency

2.400 - 2.483 GHz; 5.725 - 5.850 GHz

Max Transmission Distance(Unobstructed, free of interference)

2.400 - 2.483 GHz; 5.725 - 5.850 GHz
FCC: 8000 m
CE: 5000 m
SRRC: 5000 m
MIC: 5000 m

Operating Temperature Range

0℃ to 40℃

Transmitter Power(EIRP)

2.4 - 2.4835 GHz
FCC：≤26 dBm；CE：≤20 dBm；SRRC：≤20 dBm MIC：≤20 dBm
5.725 - 5.850 GHz
FCC：≤26 dBm；CE：≤14 dBm；SRRC：≤26 dBm

Battery

3950mAh

Charging Time

2 hours 15 min

Operating Current/Voltage

1800mA ⎓ 3.83V

Mobile Device Holder

Thickness Supported:6.5-8.5 mm，Max length: 160 mm

RC Size

Folded： 145×80×48 mm (L×W×H)
Unfolded: 190×115×100 mm (L×W×H)

Supported USB port types

Lightning, Micro USB (Type-B), USB Type-C™

Dimensions

68x60x41 mm

Port Type

USB Micro-B

Operating Range

30 m

Power

Max 26W

Illuminance

FOV17°, Max：11lux @ 30m Straight

Dimensions

68x40x27.8 mm

Port Type

USB Micro-B

Power

Avg. 1.6W

Controllable Range

5000 m

Light intensity

Min Angle：55 cd；
Light intensity：157 cd

Dimensions

68x55x65 mm

Port Type

USB Micro-B

Power

Max 10W

Decibel

100 db @ 1 meter distance

Bitrate

16 kbps

Footnotes

[1] Remote controller required.

[2] Omnidirectional Obstacle Sensing includes left/right, up/down, and forward/backward obstacle sensing. Sensing for left/right directions is only available in ActiveTrack or Tripod Mode. Omnidirectional Obstacle Sensing does not fully cover the circumference of a 360-degree arc. And left and right obstacle sensing system only works in specific modes and environments. DJI warranty does not cover any loss caused by crashing when flying left or right, even when ActiveTrack or Tripod mode is activated. Please be aware of your surroundings and App notifications when operating the Mavic 2 to ensure safety. These specs have been determined through tests conducted with the latest firmware. Firmware updates can enhance performance, so updating to the latest firmware is highly recommended."

[3]These specs have been determined through tests conducted with the latest firmware. Firmware updates can enhance performance, so updating to the latest firmware is highly recommended."

Mechanical Range

Tilt: -135 – +45°
Pan: -100 – +100°

Controllable Range

Tilt: -90 – +30°
Pan: -75 – +75°

Stabilization

3-axis (tilt, roll, pan)

Max Control Speed (tilt)

120°/s

Angular Vibration Range

±0.005°

Sensor

1/2.3” CMOS；
Effective pixels:12 Megapixels

Lens

FOV：82.6°(24 mm)；47.8°(48 mm)
Format equivalent：24-48 mm
Aperture：f/2.8(24 mm)-f/3.8(48 mm)
Auto focus at ：0.5 - ∞

ISO Range

Video：
100-3200
Photo：
100-1600(Auto)
100-3200(Manual)

Shutter Speed

8-1/8000s

Still Image Size

4000×3000

Still Photography Modes

Single shot
Burst shooting: 3/5/7 frames
Auto Exposure Bracketing (AEB): 3/5 bracketed frames at 0.7 EV Bias
Interval (JPEG: 2/3/5/7/10/15/20/30/60s RAW:5/7/10/15/20/30/60s)

Video Resolution

4K: 3840×2160 24/25/30p
2.7K: 2720×1530 24/25/30/48/50/60p
FHD: 1920×1080 24/25/30/48/50/60/120p

Max Video Bitrate

100 Mbps

Color Mode

D-Cinelike

Supported File System

FAT32(≤ 32 GB )；exFAT(> 32 GB)

Photo Format

JPEG，DNG (RAW)

Video Format

MP4 / MOV (MPEG-4 AVC/H.264, HEVC/H.265)

Input

100-240V， 50-60Hz， 1.8A

Output

Main: 17.6V ⎓ 3.41A or 17.0V⎓3.53
USB: 5 V ⎓ 2 A

Voltage

17.6±0.1V

Rated Power

60W

Capacity

3850 mAh

Voltage

15.4 V

Max Charging Voltage

17.6 V

Battery Type

LiPo

Energy

59.29 Wh

Net Weight

297 g

Charging Temperature

5℃ - 40℃

Operating Temperature Range

-10℃ to 40℃

Heating Methods

Manual Heating；Auto Heating

Heating Temperature

-10℃ to 6℃

Heating duration:

500s (Max)

Heating Power

55W (Max)

Charging Time

90 min

Max Charging Power

80W

Video Transmission System

OcuSync 2.0

Mobile App

DJI PILOT

Live View Quality

Remote Controller:
720p@30fps / 1080p@30fps

Max Live View Bitrate

40 Mbps

Latency

120 - 130 ms

Required Operating Systems

ios 9.0 or later Android 4.4.0 or later

Supported SD Cards

Micro SD™

Supporting Micro SD with capacity up to 128 GB and R/W speed up to UHS-I Speed Grade 3
